Application

Spray-Fluid Dynamics and Microfluidics

Spray formation, droplet behavior and microfluidic systems

Overview

For years, high-speed imaging has been utilized in the following industries for Fluid Dynamics research and analysis: Automotive, Aerospace, Biotech and Medical, Marine Propulsion, and Electronics. high-speed imaging provides an indispensable tool to measure and to visualize the complex movement of liquids, gases and plasmas in motion. Various imaging techniques from backlit illumination, particle image velocimetry (PIV) and schlieren imaging help researchers understand dynamic motion in tanks, wind tunnels and spray chambers. High Speed Imaging also offers various software for fluid flow analysis, namely PIV software. High Speed Imaging has partnered with Microvec Pte. Ltd., a global supplier of PIV systems with innovative and patented techniques and increased level of sophistication and complexity, including newest techniques like Pressure PIV, Tomographic PIV, Light Field PIV and AI PIV.

Recommended for This Application

Photron

FASTCAM Orion

Microvec

2D PIV

Microvec

AI PIV

Microvec

3D PIV

Microvec

Tomo PIV

Microvec

PLIF

Talk to an Expert

Also Relevant

Photron

High-Speed CamerasUltra High-Speed Cameras

FASTCAM Nova S

The FASTCAM NOVA brings together unique CMOS image sensor technologies and extensive high-speed digital imaging expertise to provide a camera with the flexibility to be used in a wide variety of applications. Available in four different models, the FASTCAM NOVA offers 12-bit image recording rates up to 16,000frames per second (fps) at megapixel image resolution, and shutter speeds to 0.2μs. Recording rates to1,100,000fps are available at reduced image resolution. All of this available from a camera that is rugged, compact, lightweight and provides the best light sensitivity in its class.

View Details

Photron

High-Speed CamerasUltra High-Speed Cameras

FASTCAM Mini AX

The FASTCAM Mini AX is Photron’s highest performance model within the FASTCAM Mini series of high-speed cameras. The Mini AX delivers exceptional light sensitivity, excellent image quality and flexible region of interest (ROI) features for customers who do not require the ultimate frame rate performance of the FASTCAM SA-X2 and SA-Z, but would benefit from the same high-end camera image sensor features.

View Details

Photron

Ultra High-Speed Cameras

Pharsighted E9 (Distributed by Photron)

Introducing the Pharsighted E9•80S and E9•100S—trailblazers in ultra high-speed photography! These revolutionary full-frame, backside-illuminated cameras offer incredible light sensitivity and exceptional speed, making them perfect for capturing stunning visuals at over 100,000 fps. Get ready to elevate your imaging experience!

View Details

Shimadzu

High-Speed CamerasUltra High-Speed Cameras

HPV-X2

Medical science and engineering have made dramatic progress thanks to visualization technology. Examples include the invention of microscopes capable of enlarged observations of phenomena occurring in the microscopic domain, invisible to the human eye, X-ray inspection systems, which enable the observation of images utilizing light at imperceptible wavelengths, and infrared cameras. Our eyes are incapable of capturing phenomena occurring at times shorter than 50 to 100 ms. As a result, high-speed video cameras have become necessary in order to record phenomena occurring at intervals that cannot be seen with the human eye, and then replay them at a slower rate so that they can be visualized. As the standard tool for visualizing ultra high-speed domains, the Hyper Vision high-speed video camera contributes to our understanding of ultra high-speed phenomena in a variety of fields.

View Details

Shimadzu

High-Speed CamerasUltra High-Speed Cameras

HPV-X3

Shimadzu Hyper Vision HPV-X3: Capture What Others Miss The Shimadzu Hyper Vision HPV-X3 sets a new benchmark in ultra-high-speed imaging, capturing the fastest events with unmatched clarity and precision. Designed for demanding applications in aerospace, defense, and scientific research, the HPV-X3 delivers frame rates of up to 20 million frames per second (fps) without compromising on image quality. Boasting an impressive 628x480 pixels and 25 nsec exposure times at 20 MHz, this camera delivers unrivaled performance.

View Details

Xcitex

Analysis & Control Software

ProAnalyst

Calibrate scenes, process videos, track motion, and graph motion data with the award-winning ProAnalyst software. Track motion, instead of markers ProAnalyst 2023 is the newest, most powerful version of ProAnalyst yet, with 20+ analysis toolkits available. ProAnalyst 2023 gives you the tools you need to tackle any motion analysis application. Stabilize, calibrate, and process images to prepare for analysis Track features to measure motion quantities in 2-D and in 3‑D Compute angle and distance measurements from tracked features Graph motion data inside ProAnalyst and export to a variety of formats

View Details

Need a solution for Spray-Fluid Dynamics and Microfluidics?

Our team matches your application to the exact camera, lens, and software stack it needs.
